SKU: 20304-TVP-MB
20304TVP Barrel Roller Bearing with Cylindrical Bore 20x52x15mm - Allow 2-3 Days
- Regular price
- €125.20 ex VAT
- Sale price
- €125,20
- Regular price
-
Not in stock
Quantity Price Breaks
3
€111.43
4
€105.17
9
€103.92
19
€102.66
29
€101.41
39
€100.16
49
€93.90
59
€92.65
249
€91.40
499
€90.14
999
€87.64
SKU:
20304-TVP-MB
20304TVP Barrel Roller Bearing with Cylindrical Bore 20x52x15mm - Allow 2-3 Days
- Regular price
- €125.20 ex VAT
- Sale price
- €125,20
- Regular price
-
Description
|
Barrel Roller Bearings: These bearings are single row, self aligning roller bearings. They consist of solid outer rings with a concave raceway, solid inner rings with two ribs and barrel rollers with cages. This bearing has a cylindrical bore and a solid window cage made from glass fibre reinforced polyamide. The bearings can be lubricated from the end faces using oil or grease. Suitable for operating temperatures up to +120 deg C. Benefits: Suitable where high radial shock type loads occur and where misalignments up to 4 degrees must be compensated. |
Technical
| d | = | 20mm |
| D | = | 52mm |
| B | = | 15mm |
| r min | = | 1.1mm |
| D1 | = | 43.5mm |
| da min | = | 27mm |
| Da max | = | 45mm |
| ra max | = | 1mm |
| Dynamic Load Cr | = | 27000 N |
| Static Load C0r | = | 24500 N |
| Fatigue limit load Cur | = | 2300 N |
| Limiting speed nG | = | 7000 rpm |
| Weight | = | 0.152 kg |
