SKU: 3302-2RS-EU
33022RS Budget Rubber Sealed Double Row Angular Contact Ball Bearing 15x42x19mm
- Regular price
- €24.48 ex VAT
- Sale price
- €24,48
- Regular price
-
Not in stock
Quantity Price Breaks
10
€21.79
19
€20.56
29
€20.32
39
€20.07
49
€19.83
74
€19.58
99
€18.36
199
€18.12
249
€17.87
499
€17.63
999
€17.14
SKU:
3302-2RS-EU
33022RS Budget Rubber Sealed Double Row Angular Contact Ball Bearing 15x42x19mm
- Regular price
- €24.48 ex VAT
- Sale price
- €24,48
- Regular price
-
Description
DRACS1_DESC
Note: Due to the differences amongst the standard specifications of different brands, this bearing may come with a polyamide or steel cage. Please contact our Sales Support team if you need to check the specification before purchase.
Note: Due to the differences amongst the standard specifications of different brands, this bearing may come with a polyamide or steel cage. Please contact our Sales Support team if you need to check the specification before purchase.
Technical
| d | = | 15mm |
| D | = | 42mm |
| B | = | 19mm |
| Dynamic load C | = | 15.1 kN |
| Static load Co | = | 9.3 kN |
| Fatigue load limit Pu | = | 0.4 kN |
| Reference speed | = | 12000 rpm |
| Weight | = | 0.13 kg |
| d1 | = | 23.7mm |
| D1 | = | 35.7mm |
| r1r2 min | = | 1mm |
| a | = | 24mm |
| da min | = | 20.6mm |
| da max | = | 23.5mm |
| Da max | = | 36.4mm |
| ra max | = | 1mm |
