SKU: 3309-2RS-EU
33092RS Budget Rubber Sealed Double Row Angular Contact Ball Bearing 45x100x39.7mm
- Regular price
- €79.93 ex VAT
- Sale price
- €79,93
- Regular price
-
Not in stock
Quantity Price Breaks
10
€71.14
19
€67.14
29
€66.34
39
€65.54
49
€64.74
74
€63.94
99
€59.95
199
€59.15
249
€58.35
499
€57.55
999
€55.95
SKU:
3309-2RS-EU
33092RS Budget Rubber Sealed Double Row Angular Contact Ball Bearing 45x100x39.7mm
- Regular price
- €79.93 ex VAT
- Sale price
- €79,93
- Regular price
-
Description
DRACS1_DESC
Note: Due to the differences amongst the standard specifications of different brands, this bearing may come with a polyamide or steel cage. Please contact our Sales Support team if you need to check the specification before purchase.
Note: Due to the differences amongst the standard specifications of different brands, this bearing may come with a polyamide or steel cage. Please contact our Sales Support team if you need to check the specification before purchase.
Technical
| d | = | 45mm |
| D | = | 100mm |
| B | = | 39.7mm |
| Dynamic load C | = | 75 kN |
| Static load Co | = | 53 kN |
| Fatigue load limit Pu | = | 2.24 kN |
| Reference speed | = | 4800 rpm |
| Weight | = | 1.25 kg |
| d1 | = | 55.6mm |
| D1 | = | 90mm |
| r1r2 min | = | 1.5mm |
| a | = | 58mm |
| da min | = | 54mm |
| da max | = | 55.5mm |
| Da max | = | 91mm |
| ra max | = | 1.5mm |
