SKU: 3312-2RS-EU
33122RS Budget Rubber Sealed Double Row Angular Contact Ball Bearing 60x130x54mm
- Regular price
- €80.14 ex VAT
- Sale price
- €80,14
- Regular price
-
ex VAT
In stock
Quantity Price Breaks
10
€71.32
19
€67.32
29
€66.52
39
€65.71
49
€64.91
74
€64.11
99
€60.11
199
€59.30
249
€58.50
499
€57.70
999
€56.10
Description
DRACS1_DESC
Note: Due to the differences amongst the standard specifications of different brands, this bearing may come with a polyamide or steel cage. Please contact our Sales Support team if you need to check the specification before purchase.
Note: Due to the differences amongst the standard specifications of different brands, this bearing may come with a polyamide or steel cage. Please contact our Sales Support team if you need to check the specification before purchase.
Technical
| d | = | 60mm |
| D | = | 130mm |
| B | = | 54mm |
| Dynamic load C | = | 127 kN |
| Static load Co | = | 95 kN |
| Fatigue load limit Pu | = | 4.05 kN |
| Weight | = | 2.8 kg |
| d1 | = | 73.4mm |
| D1 | = | 118mm |
| r1r2 min | = | 2.1mm |
| a | = | 78mm |
| da min | = | 72mm |
| da max | = | 73mm |
| Da max | = | 118mm |
| ra max | = | 2mm |
