SKU: 50AT10/890
50AT10/890 ContiTech Standard Synchroflex Timing Belt 50mm Width 10mm Pitch 89 Teeth
- Regular price
- €108.87 ex VAT
- Sale price
- €108,87
- Regular price
-
Not in stock
Quantity Price Breaks
3
€96.89
5
€91.45
10
€90.36
15
€89.27
20
€88.18
30
€87.10
40
€81.65
50
€80.56
60
€79.48
75
€78.39
100
€76.21
SKU:
50AT10/890
50AT10/890 ContiTech Standard Synchroflex Timing Belt 50mm Width 10mm Pitch 89 Teeth
- Regular price
- €108.87 ex VAT
- Sale price
- €108,87
- Regular price
-
Description
AT Standard SYNCHROFLEX® Timing Belts: This belt is manufactured by ContiTech, specialists in rubber and plastics technology. This Synchroflex belt is a truly endless belt, suitable for AT pulleys.
Standard Synchroflex belts consist of just two components, a wear-resistant Contilan carcass and high-grade endless steel wire tension members. This construction provides high flank load capacity and low elastic elongation which makes them unsurpassed for quality and accuracy.
Benefits: High power AT profile, low elastic elongation and high flank load capacity.
Technical
| No of Teeth | = | 89 |
| Belt Width | = | 50mm |
| Belt Pitch | = | 10mm (AT10) |
| Belt Length | = | 890mm |
| Belt Thickness (hs) | = | 2.5mm |
| Tooth Height (ht) | = | 2.5mm |
| Tooth Pitch (t) | = | 10mm |
| Flank Angle (f) | = | 50 deg |
| Tension Member Loadings | = | 7750 N |
| Belt Weight (per metre) | = | 0.315kg |
