SKU: 53210+U210-EU
53210 Budget Single Thrust Ball Bearing with Spherical Housing Seat U210 50x78x26mm
- Regular price
- €43.35 ex VAT
- Sale price
- €43,35
- Regular price
-
ex VAT
In stock
Quantity Price Breaks
10
€38.58
19
€36.41
29
€35.98
39
€35.55
49
€35.11
74
€34.68
99
€32.51
199
€32.08
249
€31.65
499
€31.21
999
€30.35
Description
|
Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
Technical
| d | = | 50mm |
| D | = | 78mm |
| H1 | = | 26mm |
| Dynamic load C | = | 49.4 kN |
| Static load Co | = | 116 kN |
| Fatigue load limit Pu | = | 4.3 kN |
| Minimum load factor A | = | 0.069 |
| Reference speed | = | 3400 rpm |
| Limiting Speed | = | 4500 rpm |
| Weight | = | 0.47 kg |
| Seating Washer | = | U210 |
| d1 | = | 78mm |
| D1 | = | 52mm |
| D2 | = | 62mm |
| D3 | = | 82mm |
| H | = | 23.49mm |
| C | = | 7.5mm |
| R | = | 64mm |
| s | = | 32.5mm |
| r1r2 min | = | 1mm |
| da max | = | 67mm |
| Da max | = | 62mm |
| ra max | = | 1mm |
