SKU: EXF310-SNR
SNR EXF310 Metric Four Bolt Square Cast Iron Flange Housing with 50mm Bore Eccentric Collar Insert
- Regular price
- €98.10 ex VAT
- Sale price
- €98,10
- Regular price
-
In stock
Quantity Price Breaks
3
€87.31
4
€82.40
9
€81.42
19
€80.44
49
€79.46
99
€78.48
499
€73.58
999
€72.59
1999
€71.61
2999
€70.63
4999
€68.67
SKU:
EXF310-SNR
SNR EXF310 Metric Four Bolt Square Cast Iron Flange Housing with 50mm Bore Eccentric Collar Insert
- Regular price
- €98.10 ex VAT
- Sale price
- €98,10
- Regular price
-
Description
|
UCF or SF Series 4 Bolt Square Cast Iron Housings: Bearing units supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| --- | = | Dimensions |
| Shaft diameter d | = | 50mm |
| A | = | 48mm |
| A1 | = | 20mm |
| A2 | = | 70mm |
| B | = | 49.2mm |
| B1 | = | 66.6mm |
| d1 | = | 76.2mm |
| e | = | 28mm |
| J | = | 132mm |
| L | = | 175mm |
| N | = | 23mm |
| S | = | 24.6mm |
| G | = | M6x1 |
| --- | = | Load rating |
| Dynamic load C | = | 62 kN |
| Static load C0 | = | 37.8 kN |
| --- | = | Unit information |
| Operating temperature min. | = | -20& |
| deg | = | C |
| Operating temperature max. | = | 100& |
| deg | = | C |
| Recommended tightening torque for set screw | = | 22 Nm |
| Mass | = | 4.56 kg |
