SKU: EXF312-SNR
SNR EXF312 Metric Four Bolt Square Cast Iron Flange Housing with 60mm Bore Eccentric Collar Insert
- Regular price
- €147.15 ex VAT
- Sale price
- €147,15
- Regular price
-
In stock
Quantity Price Breaks
3
€130.96
4
€123.61
9
€122.13
19
€120.66
49
€119.19
99
€117.72
499
€110.36
999
€108.89
1999
€107.42
2999
€105.95
4999
€103.01
SKU:
EXF312-SNR
SNR EXF312 Metric Four Bolt Square Cast Iron Flange Housing with 60mm Bore Eccentric Collar Insert
- Regular price
- €147.15 ex VAT
- Sale price
- €147,15
- Regular price
-
Description
|
UCF or SF Series 4 Bolt Square Cast Iron Housings: Bearing units supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| --- | = | Dimensions |
| Shaft diameter d | = | 60mm |
| A | = | 56mm |
| A1 | = | 22mm |
| A2 | = | 81.45mm |
| B | = | 61.9mm |
| B1 | = | 79.4mm |
| d1 | = | 89mm |
| e | = | 33mm |
| J | = | 150mm |
| L | = | 193mm |
| N | = | 23mm |
| S | = | 30.95mm |
| G | = | M6x1 |
| --- | = | Load rating |
| Dynamic load C | = | 81.6 kN |
| Static load C0 | = | 51.8 kN |
| --- | = | Unit information |
| Operating temperature min. | = | -20& |
| deg | = | C |
| Operating temperature max. | = | 100& |
| deg | = | C |
| Recommended tightening torque for set screw | = | 22 Nm |
| Mass | = | 6.62 kg |
