SKU: FL48-PBC
PBC FL 48 Imperial Closed Precision Linear Plain Bearings with Frelon Gold 3x4.5x6 inch (Allow 2-3 Days)
- Regular price
- €589.62 ex VAT
- Sale price
- €589,62
- Regular price
-
Not in stock
Quantity Price Breaks
3
€524.76
5
€495.28
9
€489.38
19
€483.49
49
€477.59
74
€471.70
99
€442.22
199
€436.32
249
€430.42
499
€424.53
999
€412.73
SKU:
FL48-PBC
PBC FL 48 Imperial Closed Precision Linear Plain Bearings with Frelon Gold 3x4.5x6 inch (Allow 2-3 Days)
- Regular price
- €589.62 ex VAT
- Sale price
- €589,62
- Regular price
-
Description
PBC FL Imperial Closed Linear Plain Bearings with Frelon Gold Liner: These compact precision linear bearings are designed to be interchangeable with compact ball bearings and bronze bushings. The Frelon GOLD® has a dark gold high-performance material compatible with RC60 hardened steel shafting, RC70 ceramic coated, and 440 stainless steel shafting.
Benefits: Self-lubricating for oil-free operation, Static Load Capacities up to 446 kN, Wide temperature range from -240 to 204 degree C
Technical
| Inside Diameter | = | 76.2mm = 3 inch |
| Outside Diameter | = | 114.3mm = 4.5 (4-1/2) inch |
| Width | = | 152.4mm = 6 inch |
| Nominal Bore Size | = | 3 inch |
| Effective Surface Area (Square Inch) | = | 18.8kg |
| Max Static Load | = | 250.67kN |
| Weight | = | 2.229kg |
