SKU: MFC50-RHP
RHP MFC50 Four Bolt Round Cast Iron Flanged Bearing Unit and 50mm Insert
- Regular price
- €150.85 ex VAT
- Sale price
- €150,85
- Regular price
-
In stock
Quantity Price Breaks
10
€134.26
20
€126.71
30
€125.21
40
€123.70
50
€122.19
75
€120.68
100
€113.14
200
€111.63
250
€110.12
500
€108.61
1000
€105.60
SKU:
MFC50-RHP
RHP MFC50 Four Bolt Round Cast Iron Flanged Bearing Unit and 50mm Insert
- Regular price
- €150.85 ex VAT
- Sale price
- €150,85
- Regular price
-
Description
|
RHP MFC Series Heavy Duty 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. |
Technical
| Bore | = | 50mm |
| L | = | 161.9mm |
| H | = | 114.3mm |
| J | = | 136.52mm |
| G | = | 10mm |
| A1 | = | 39.67mm |
| A4 | = | 19mm |
| A5 | = | 6.4mm |
| B | = | 55.55mm |
| s | = | 22.28mm |
| d1 | = | 68.81mm |
| Dynamic load | = | 43500 N |
| Static load | = | 29200 N |
| Rec max speed | = | 3100 rpm |
| Weight | = | 3 kg |
| Insert | = | < |
| a href=" | = | advanced_search_result.php?keywords=1055-50G+insonly" |
| > | = | 1055-50G Click Here< |
| /a> | = | |
| Casting group | = | 5 |
| Grease nipple thread | = | 1/4 UNF, 1/4 inch x 28 TPI |
