SKU: NKXR15Z-MB
Major Brand NKXR15Z Needle Roller Thrust Bearing without Cover 15x24x23mm
- Regular price
- €82.97 ex VAT
- Sale price
- €82,97
- Regular price
-
In stock
Quantity Price Breaks
10
€73.84
19
€69.69
29
€68.87
39
€68.04
49
€67.21
74
€66.38
99
€62.23
199
€61.40
249
€60.57
499
€59.74
999
€58.08
SKU:
NKXR15Z-MB
Major Brand NKXR15Z Needle Roller Thrust Bearing without Cover 15x24x23mm
- Regular price
- €82.97 ex VAT
- Sale price
- €82,97
- Regular price
-
Description
|
Needle Roller / Ball Roller Thrust Combination: Of a none separable design, the outer ring with integral housing washer and integral needle roller cage assembly. Benefits: High thrust loading, easily mounted |
Technical
| Fw | = | 15mm |
| D | = | 24mm |
| C | = | 23mm |
| Dynamic load | = | 11200 N |
| Static load | = | 14000 N |
| Axial dynamic load | = | 11200 N |
| Axial static load | = | 27000 N |
| Fatigue load limit radial Pu | = | 1660 N |
| Fatigue load limit axial Pu | = | 2450 N |
| Min load factor A | = | 0.058 |
| Speed in grease | = | 3200 rpm |
| Speed in oil | = | 4300 rpm |
| C1 | = | 9mm |
| C2 | = | 6.5mm |
| d | = | 15 |
