SKU: SAKB6F-SKF
SKF SAKB6F Right Hand Steel / PTFE FRP Lined Plain Male Rod End M6 Thread
- Regular price
- €27.58 ex VAT
- Sale price
- €27,58
- Regular price
-
Not in stock
Quantity Price Breaks
10
€24.55
19
€23.17
29
€22.89
39
€22.62
49
€22.34
74
€22.06
99
€20.69
199
€20.41
249
€20.13
499
€19.86
999
€19.31
SKU:
SAKB6F-SKF
SKF SAKB6F Right Hand Steel / PTFE FRP Lined Plain Male Rod End M6 Thread
- Regular price
- €27.58 ex VAT
- Sale price
- €27,58
- Regular price
-
Description
|
SKF SAKB..F Series Rod End Bearings: This series is classed as maintenance free rod end bearings. Comprising of sliding contact surfaces of steel against PTFE impregnated fibre re-in forced polymer (FRP) these rod end bearings are unsealed and will operate within -40deg C to +75 deg C, load carrying capacity will be reduced over +50 degrees C. Rod ends with a Steel / PTFE FRP sliding contact surface combination consist of a rod end housing and a spherical plain bearing inner ring. Between the housing and the inner ring, a sliding layer of fibre reinforced polymer, containing PTFE, is molded to the housing. Left and Right hand threaded versions are available an L in the part number denotes the left hand option. These are metric sized rod end bearings. Application: Suitable for heavy, constant direction loads, where low coefficient of friction is required; limited suitability for alternating loads, shock loads. Benefits: Maintenance free, Steel / PTFE FRP |
Technical
| d | = | 6mm |
| d2 max | = | 21mm |
| G | = | M6 |
| B | = | 9mm |
| C1 max | = | 6.75mm |
| h | = | 36mm |
| a | = | 13deg |
| Dynamic load C | = | 4.25 kN |
| Static load Co | = | 6.8 kN |
| Weight | = | 0.021 kg |
| dk | = | 12.7mm |
| l1 min | = | 21mm |
| l2 max | = | 48mm |
| r1 min | = | 0.3mm |
