SKU: SL033_IMP_NAK
NAK SL033 Hardened Stainless Sleeve for Shafts 1.173-1.178 inch - Allow 7-10 Days
- Regular price
- €25.59 ex VAT
- Sale price
- €25,59
- Regular price
-
ex VAT
Not in stock
Quantity Price Breaks
10
€22.78
19
€21.50
29
€21.24
39
€20.98
49
€20.73
74
€20.47
99
€19.19
199
€18.94
249
€18.68
499
€18.42
999
€17.91
Description
NAK Wear-Pro Shaft Protection Sleeves: Wear-Pro Sleeves offer an excellent sealing surface for radial shaft seals whilst reducing costly shaft machining or maintenance. These sleeves can be used anywhere with a radial shaft seal, such as in industrial gearboxes, motors, pumps, reducers, construction, agricultural equipment and automotive parts.
Benefits: Simple and quick installation, cost-effective, high-grade surface
Technical
| Shaft Diameter Range (A) | = | 1.173-1.178 inch |
| Nominal Shaft Diameter (A) | = | 1.175 inch |
| Flange Diameter (D) | = | 1.402 inch |
| Width on Shaft (X) | = | 0.315 inch |
| Overall Width (Y) | = | 0.437 inch |
| Installation Depth (Z) | = | 0.689 inch |
| Flange Diameter (D) Tolerance | = | 1.6mm |
| Width on Shaft (X) Tolerance | = | 0.8mm |
| Overall Width (Y) Tolerance | = | 0.8mm |
