RHP SLC1-7/16DEC Cast Iron Cartridge Unit with 1-7/16 inch Bore Insert 98.45mm Outside Diameter

SKU: SLC1.7/16DEC-RHP

RHP SLC1-7/16DEC Cast Iron Cartridge Unit with 1-7/16 inch Bore Insert 98.45mm Outside Diameter

€79.05 ex VAT
€79,05
ex VAT
Not in stock

Quantity Price Breaks

10 €70.35
20 €66.40
30 €65.61
40 €64.82
50 €64.03
75 €63.24
100 €59.29
200 €58.50
250 €57.71
500 €56.92
1000 €55.34
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
RHP SLC1-7/16DEC Cast Iron Cartridge Unit with 1-7/16 inch Bore Insert 98.45mm Outside Diameter
SKU: SLC1.7/16DEC-RHP

RHP SLC1-7/16DEC Cast Iron Cartridge Unit with 1-7/16 inch Bore Insert 98.45mm Outside Diameter

€79.05 ex VAT
€79,05
ex VAT

Description

RHP SLC DEC Series Cartridge Bearing Units: Cast iron cartridge bearing unit supplied with a full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has an eccentric collar and grub screw to allow tightening against the shaft after installation. Cartridge units allow a self aligning bearing inserts to be used where a fixed bearing would normally be used.
The insert can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, eccentric collar fixing, full width insert

Technical

Bore = 1-7/16 inch
L = 3.876 inch
A = 1.219 inch
A3 = 1.881 inch
B3 = 2015 inch
s2 = 0.744 inch
d2 = 2.188 inch
Dynamic load Cr = 25700 N
Static load Cor = 15300 N
Rec max speed = 4500 rpm
Weight = 1.4 kg
Insert = <
a href=" = advanced_search_result.php?keywords=1035-1-7/16DECG+insonly"
> = 1035-1-7/16DECG Click Here<
/a> =
Casting group = 5
Grease nipple thread = 1/4 UNF, 1/4 inch x 28 TPI
