SKU: SSUCT.206
SSUCT206 Metric Stainless Steel Take Up Unit Housing with 30mm Bore Stainless Insert
- Regular price
- €110.89 ex VAT
- Sale price
- €110,89
- Regular price
-
In stock
Quantity Price Breaks
3
€98.69
4
€93.15
9
€92.04
19
€90.93
49
€89.82
99
€88.71
499
€83.17
999
€82.06
1999
€80.95
2999
€79.84
4999
€77.62
SKU:
SSUCT.206
SSUCT206 Metric Stainless Steel Take Up Unit Housing with 30mm Bore Stainless Insert
- Regular price
- €110.89 ex VAT
- Sale price
- €110,89
- Regular price
-
Description
|
SSUCT or ST Series Stainless Steel Take up Units: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
Technical
| d | = | 30mm |
| o | = | 16mm |
| g | = | 10mm |
| p | = | 56mm |
| q | = | 37mm |
| s | = | 22mm |
| b | = | 57mm |
| K | = | 12mm |
| e | = | 89mm |
| a | = | 102mm |
| w | = | 113mm |
| j | = | 37mm |
| l | = | 28mm |
| h | = | 70mm |
| Bi | = | 38.1mm |
| n | = | 15.9mm |
| Weight | = | 1.3 kg |
| Dynamic load | = | 1520 kgf |
| Static load | = | 1020 kgf |
| Rec max speed | = | 5300 rpm |
