SKU: SSUCT.207
SSUCT207 Metric Stainless Steel Take Up Unit Housing with 35mm Bore Stainless Insert
- Regular price
- €133.54 ex VAT
- Sale price
- €133,54
- Regular price
-
Not in stock
Quantity Price Breaks
3
€118.85
4
€112.17
9
€110.84
19
€109.50
49
€108.17
99
€106.83
499
€100.16
999
€98.82
1999
€97.48
2999
€96.15
4999
€93.48
SKU:
SSUCT.207
SSUCT207 Metric Stainless Steel Take Up Unit Housing with 35mm Bore Stainless Insert
- Regular price
- €133.54 ex VAT
- Sale price
- €133,54
- Regular price
-
Description
|
SSUCT or ST Series Stainless Steel Take up Units: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
Technical
| d | = | 35mm |
| o | = | 16mm |
| g | = | 13mm |
| p | = | 64mm |
| q | = | 37mm |
| s | = | 22mm |
| b | = | 64mm |
| K | = | 12mm |
| e | = | 89mm |
| a | = | 102mm |
| w | = | 129mm |
| j | = | 37mm |
| l | = | 30mm |
| h | = | 78mm |
| Bi | = | 42.9mm |
| n | = | 17.5mm |
| Weight | = | 1.3 kg |
| Dynamic load | = | 2010 kgf |
| Static load | = | 1390 kgf |
| Rec max speed | = | 4500 rpm |
