SKU: SSUCT.210
SSUCT210 Metric Stainless Steel Take Up Unit Housing with 50mm Bore Stainless Insert
- Regular price
- €222.29 ex VAT
- Sale price
- €222,29
- Regular price
-
In stock
Quantity Price Breaks
3
€197.84
4
€186.72
9
€184.50
19
€182.28
49
€180.05
99
€177.83
499
€166.72
999
€164.49
1999
€162.27
2999
€160.05
4999
€155.60
SKU:
SSUCT.210
SSUCT210 Metric Stainless Steel Take Up Unit Housing with 50mm Bore Stainless Insert
- Regular price
- €222.29 ex VAT
- Sale price
- €222,29
- Regular price
-
Description
|
SSUCT or ST Series Stainless Steel Take up Units: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
Technical
| d | = | 50mm |
| o | = | 19mm |
| g | = | 16mm |
| p | = | 83mm |
| q | = | 49mm |
| s | = | 29mm |
| b | = | 86mm |
| K | = | 16mm |
| e | = | 102mm |
| a | = | 117mm |
| w | = | 149mm |
| j | = | 49mm |
| l | = | 37mm |
| h | = | 90mm |
| Bi | = | 51.6mm |
| n | = | 19mm |
| Weight | = | 2.5 kg |
| Dynamic load | = | 2750 kgf |
| Static load | = | 2020 kgf |
| Rec max speed | = | 3400 rpm |
