SKU: TBS-D-16B-17

17 Tooth 16B Duplex Sprocket Tapered Locking Bush Type for 1 inch Pitch Chain (Bush not Incl.)

€67.15 ex VAT
€67,15
ex VAT
Equivalent to: 16B2 TS82-17 82-17
In stock

Quantity Price Breaks

5 €59.76
9 €56.41
19 €55.73
29 €55.06
49 €54.39
74 €53.72
99 €50.36
199 €49.69
249 €49.02
499 €48.35
999 €47.01
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
17 Tooth 16B Duplex Sprocket Tapered Locking Bush Type for 1 inch Pitch Chain (Bush not Incl.)
17 Tooth 16B Duplex Sprocket Tapered Locking Bush Type for 1 inch Pitch Chain (Bush not Incl.)
17 Tooth 16B Duplex Sprocket Tapered Locking Bush Type for 1 inch Pitch Chain (Bush not Incl.)
17 Tooth 16B Duplex Sprocket Tapered Locking Bush Type for 1 inch Pitch Chain (Bush not Incl.)
SKU: TBS-D-16B-17

17 Tooth 16B Duplex Sprocket Tapered Locking Bush Type for 1 inch Pitch Chain (Bush not Incl.)

€67.15 ex VAT
€67,15
ex VAT

Description

Tapered Bore Sprockets: Small sprockets are usually manufactured from C45 Steel and the large sprockets maybe supplied in G22 Cast Iron. These taper bore sprockets accept tapered locking bushes in a wide variety of shaft sizes to allow the end user to easily fit the sprocket to the shaft with minimal effort and no machining.
Available in a comprehensive range of British Standard Simplex, Duplex and Triplex sizes. Pilot Bore variants available if required.
Benefits: Universal on the shelf stock - wide range of tapered locking bushes and shaft sizes available to choose from. Durable and hard-wearing.

Technical

Tooth Radius r3 = 26mm
Chamfer c = 2.5mm
Tooth Width b1 = 15.8mm
Tooth Width B1 = 16.2mm
Tooth Width B2 = 47.7mm
Tooth Width B3 = 79.6mm
Pitch = 25.4mm
Width Between Inner = 17.02mm
Roller Diameter = 15.88mm
No. of Teeth = 17
Outer Diameter de = 149mm
Pitch Diameter dp = 138.22mm
Length Through Bore A = 47.7mm
Reference = 82-17
Taper Bush = <
a href=advanced_search_result.php?sort=2a& = search_in_description=1&
keywords=2517+tapered+locking+bush> = 2517 Click Here<
/a> =
