SKU: TBS-S-12B-20
20 Tooth 12B Simplex Sprocket Tapered Locking Bush Type for 3/4 inch Pitch Chain (Bush not Incl.)
- Regular price
- €31.91 ex VAT
- Sale price
- €31,91
- Regular price
-
In stock
Quantity Price Breaks
5
€28.40
9
€26.80
19
€26.49
29
€26.17
49
€25.85
74
€25.53
99
€23.93
199
€23.61
249
€23.29
499
€22.98
999
€22.34
SKU:
TBS-S-12B-20
20 Tooth 12B Simplex Sprocket Tapered Locking Bush Type for 3/4 inch Pitch Chain (Bush not Incl.)
- Regular price
- €31.91 ex VAT
- Sale price
- €31,91
- Regular price
-
Description
Tapered Bore Sprockets: Small sprockets are usually manufactured from C45 Steel and the large sprockets maybe supplied in G22 Cast Iron. These taper bore sprockets accept tapered locking bushes in a wide variety of shaft sizes to allow the end user to easily fit the sprocket to the shaft with minimal effort and no machining.
Available in a comprehensive range of British Standard Simplex, Duplex and Triplex sizes. Pilot Bore variants available if required.
Benefits: Universal on the shelf stock - wide range of tapered locking bushes and shaft sizes available to choose from. Durable and hard-wearing.
Available in a comprehensive range of British Standard Simplex, Duplex and Triplex sizes. Pilot Bore variants available if required.
Benefits: Universal on the shelf stock - wide range of tapered locking bushes and shaft sizes available to choose from. Durable and hard-wearing.
Technical
| No. of Teeth | = | 20 |
| Pitch Diameter dp | = | 121.78mm |
| Outer Diameter de | = | 130mm |
| Diameter Over Chain A | = | 138mm |
| Hub Diameter N | = | 95mm |
| Tooth Width B1 | = | 11.1mm |
| Bore Length L | = | 32mm |
| Taper Bush Series | = | < |
| a href=" | = | advanced_search_result.php?& |
| keywords=2012+taperlock" | = | > |
| 2012< | = | span style=" |
| color:blue" | = | > |
| Click Here< | = | /span> |
| < | = | /a> |
| = | Weight | |
| 1.26 kg | = | N/A |
