SKU: UC.203
UC203 Metric Bearing Insert with 17mm Bore 47mm Outside Dia
- Regular price
- €7.64 ex VAT
- Sale price
- €7,64
- Regular price
-
In stock
Quantity Price Breaks
3
€6.80
4
€6.42
9
€6.34
19
€6.26
49
€6.19
99
€6.11
499
€5.73
999
€5.65
1999
€5.58
2999
€5.50
4999
€5.35
SKU:
UC.203
UC203 Metric Bearing Insert with 17mm Bore 47mm Outside Dia
- Regular price
- €7.64 ex VAT
- Sale price
- €7,64
- Regular price
-
Description
|
UC or 10 -- G Series: Normal duty bearing insert with 2 grub screws to allow tightening against the shaft once fitted.
These inserts are ideal replacements for housed types which can easily be removed from the housings when replacement is required |
Technical
| d | = | 17mm |
| D | = | 47mm |
| Bi | = | 31mm |
| Be | = | 17mm |
| n | = | 12.7mm |
| m | = | 18.3mm |
| G | = | 4.8mm |
| Grub screw | = | M6x1 |
| Weight | = | 0.21 kg |
| Dynamic load | = | 1000 kgf |
| Static load | = | 630 kgf |
