UC208-24 Imperial Bearing Insert with 1-1/2 inch Bore 80mm Outside Dia
UC208-24 Imperial Bearing Insert with 1-1/2 inch Bore 80mm Outside Dia
UC208-24 Imperial Bearing Insert with 1-1/2 inch Bore 80mm Outside Dia
UC208-24 Imperial Bearing Insert with 1-1/2 inch Bore 80mm Outside Dia

SKU: UC.208-24

UC208-24 Imperial Bearing Insert with 1-1/2 inch Bore 80mm Outside Dia

€12.55 ex VAT
€12,55
ex VAT
Equivalent to: 1040-1-1/2G
In stock

Quantity Price Breaks

3 €11.17
4 €10.54
9 €10.42
19 €10.29
49 €10.17
99 €10.04
499 €9.41
999 €9.29
1999 €9.16
2999 €9.04
4999 €8.79
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
UC208-24 Imperial Bearing Insert with 1-1/2 inch Bore 80mm Outside Dia
UC208-24 Imperial Bearing Insert with 1-1/2 inch Bore 80mm Outside Dia
SKU: UC.208-24

UC208-24 Imperial Bearing Insert with 1-1/2 inch Bore 80mm Outside Dia

€12.55 ex VAT
€12,55
ex VAT

Description

UC or 10 -- G Series: Normal duty bearing insert with 2 grub screws to allow tightening against the shaft once fitted. These inserts are ideal replacements for housed types which can easily be removed from the housings when replacement is required
Benefits: Cost effective replacement insert, re-lubricatable, grub screw fixing

Technical

d = 1-1/2 inch
D = 80mm
Bi = 49.2mm
Be = 21mm
n = 19mm
m = 30.2mm
G = 8mm
Grub screw = 5/16"
-24 UNF = Weight
0.68 kg = Dynamic load
2560 kgf = Static load
1810 kgf = Rec max speed
4000 rpm = N/A
