SKU: UCPX.08
UCPX08 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 40mm Bore Insert
- Regular price
- €37.28 ex VAT
- Sale price
- €37,28
- Regular price
-
In stock
Quantity Price Breaks
3
€33.18
4
€31.32
9
€30.94
19
€30.57
49
€30.20
99
€29.82
499
€27.96
999
€27.59
1999
€27.21
2999
€26.84
4999
€26.10
SKU:
UCPX.08
UCPX08 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 40mm Bore Insert
- Regular price
- €37.28 ex VAT
- Sale price
- €37,28
- Regular price
-
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| d | = | 40mm |
| h | = | 58.7mm |
| a | = | 222mm |
| e | = | 156mm |
| b | = | 67mm |
| s2 | = | 32mm |
| s1 | = | 20mm |
| g | = | 26mm |
| w | = | 113mm |
| B1 | = | 49.2mm |
| n | = | 19mm |
| Bolt Size | = | M16 |
| Weight | = | 3.5 kg |
| Dynamic load | = | 2650 kgf |
| Static load | = | 1910 kgf |
| Rec max speed | = | 3700 rpm |
