SKU: UCPX.20-64
UCPX20-64 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 4 inch Bore Insert
- Regular price
- €492.18 ex VAT
- Sale price
- €492,18
- Regular price
-
Not in stock
Quantity Price Breaks
3
€438.04
4
€413.43
9
€408.51
19
€403.59
49
€398.67
99
€393.74
499
€369.14
999
€364.21
1999
€359.29
2999
€354.37
4999
€344.53
SKU:
UCPX.20-64
UCPX20-64 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 4 inch Bore Insert
- Regular price
- €492.18 ex VAT
- Sale price
- €492,18
- Regular price
-
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| d | = | 4 inch |
| h | = | 127mm |
| a | = | 432mm |
| e | = | 337mm |
| b | = | 121mm |
| s2 | = | 64mm |
| s1 | = | 33mm |
| g | = | 52mm |
| w | = | 245mm |
| B1 | = | 117.5mm |
| n | = | 49.2mm |
| Bolt Size | = | 27mm |
| Weight | = | 31.8 kg |
| Dynamic load | = | 13300 kgf |
| Static load | = | 10500 kgf |
