SKU: WSZC90-JCS
JCS WSZC90 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 70-90mm Band Width 13mm
- Regular price
- €6.44 ex VAT
- Sale price
- €6,44
- Regular price
-
In stock
Quantity Price Breaks
3
€5.73
5
€5.41
9
€5.35
19
€5.28
49
€5.22
74
€5.15
99
€4.83
199
€4.77
249
€4.70
499
€4.64
999
€4.51
SKU:
WSZC90-JCS
JCS WSZC90 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 70-90mm Band Width 13mm
- Regular price
- €6.44 ex VAT
- Sale price
- €6,44
- Regular price
-
Description
Zinc Plated Steel Hi-Grip Wing Screw: Specifically designed for frequently removed hoses, the unique dovetail locking and side lugs of the wing plate ensure excellent sealing and longevity. Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse.
Technical
| BS No. | = | 90 |
| Adjustment Range (mm) | = | 70-90mm |
| Adjustment Range (inch) | = | 2-3/4 - 3-1/2 inch |
| A | = | 7mm |
| B | = | 37mm |
| C | = | 12mm |
| D | = | 16mm |
| E | = | 13mm |
| F | = | 0.9mm |
| G | = | 24mm |
| Recommended Torque Nm | = | 6Nm |
| Recommended Torque lb-in | = | 54lb-in |
