SKU: 1/MFC4-RHP
RHP 1/MFC4 Four Bolt Round Cast Iron Flanged Bearing Unit and 4 inch Insert
RHP 1/MFC4 Four Bolt Round Cast Iron Flanged Bearing Unit and 4 inch Insert
Out of stock
Share this product
Description
Description
|
RHP MFC Series Heavy Duty 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 101.6mm = 4 inch
- Style:
- MFC
- Pitch Circle Diameter:
- 238.13mm = 9.375 inch
Technical
Technical
| Bore | 4 inch |
|---|---|
| L | 10.874 inch |
| H | 8.125 inch |
| J | 9.375 inch |
| G | 0.75 inch |
| A1 | 3.5 inch |
| A4 | 1.625 inch |
| A5 | 0.5 inch |
| B | 4.625 inch |
| s | 1.94 inch |
| d1 | 5.242 inch |
| Dynamic load | 19900 N |
| Static load | 20860 N |
| Rec max speed | 1550 rpm |
| Weight | 20 kg |
| Insert | <a href="advanced_search_result.php?keywords=205-4G+insonly">205-4G Click Here</a> |
| Casting group | 1/11 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
