• Timken 30213 Metric Taper Roller Bearing 65x120x24.75mm
  • Timken
1 2

SKU: 30213-TIM

Timken 30213 Metric Taper Roller Bearing 65x120x24.75mm

Timken 30213 Metric Taper Roller Bearing 65x120x24.75mm
€95,86 ex VAT
€95,86 ex VAT
Sale Sold out

In stock

Price Break
10+ €72,84
20+ €68,75
30+ €67,93
40+ €67,11
50+ €66,30
75+ €65,48
100+ €61,39
200+ €60,57
250+ €59,75
500+ €58,93
1000+ €57,29

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Metric Taper Roller Bearings: These bearings have tapered inner and outer raceways between which tapered roller are arranged. The design of taper rollers makes them particularly suited to accommodating combined axial and radial loads. They are supplied as a cup and cone set (inner and outer).
Benefits: Used widely in transmissions, can be used in oil or greased, high radial and axial load
Brand / Quality:
Timken - High Quality
Inside Diameter:
65mm
Outside Diameter:
120mm
Width:
24.75mm
Technical
d 65mm
D 120mm
T 24.75mm
Dynamic load 132 kN
Static load 134 kN
Fatigue load limit Pu 16.3 kN
Reference speed 4500 rpm
Limiting speed 5600 rpm
Mass 1.15 kg
d1 89mm
B 23mm
C 20mm
r1r2 min 2mm
r3r4 min 1.5mm
a 23mm
da max 78mm
db min 74mm
Da min 106mm
Da max 113mm
Db min 113mm
Ca min 4mm
Cb min 4.5mm
ra max 2mm
rb max 1.5mm
e 0.4
Y 1.5
Y0 0.8
