• Timken 32017X Metric Taper Roller Bearing 85x130x29mm
  • Timken
1 2

SKU: 32017X-TIM

Timken 32017X Metric Taper Roller Bearing 85x130x29mm

Timken 32017X Metric Taper Roller Bearing 85x130x29mm
€142,33 ex VAT
€142,33 ex VAT
Sale Sold out

In stock

Price Break
10+ €108,17
20+ €102,09
30+ €100,87
40+ €99,66
50+ €98,44
75+ €97,23
100+ €91,15
200+ €89,94
250+ €88,72
500+ €87,51
1000+ €85,07

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Metric Taper Roller Bearings: These bearings have tapered inner and outer raceways between which tapered roller are arranged. The design of taper rollers makes them particularly suited to accommodating combined axial and radial loads. They are supplied as a cup and cone set (inner and outer).
Benefits: Used widely in transmissions, can be used in oil or greased, high radial and axial load
Brand / Quality:
Timken - High Quality
Inside Diameter:
85mm
Outside Diameter:
130mm
Width:
29mm
Technical
d 85mm
D 130mm
T 29mm
Dynamic load 140 kN
Static load 224 kN
Fatigue load limit Pu 25.5 kN
Reference speed 3400 rpm
Limiting speed 4800 rpm
Mass 1.35 kg
d1 108mm
B 29mm
C 22mm
r1r2 min 1.5mm
r3r4 min 1.5mm
a 28mm
da max 94mm
db min 92mm
Da min 117mm
Da max 122mm
Db min 125mm
Ca min 6mm
Cb min 7mm
ra max 1.5mm
rb max 1.5mm
e 0.44
Y 1.35
Y0 0.8
