SKU: 5202-ZZ-KSM

KSM 5202ZZ Metal Shielded Double Row Angular Contact Ball Bearing 15x35x15.9mm

Name: KSM 5202ZZ Metal Shielded Double Row Angular Contact Ball Bearing 15x35x15.9mm
Brand: KSM
SKU: 5202-ZZ-KSM
Price: 25.96 EUR
Availability: InStock

€25,96 ex VAT

Sale Sold out

Equivalent to: 3202ZZ

In stock

Price Break

4+ €19,73

9+ €18,62

19+ €18,40

29+ €18,18

49+ €17,96

99+ €17,74

179+ €16,63

249+ €16,41

499+ €16,18

699+ €15,96

999+ €15,52

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Metal Shielded Double Row Angular Contact Ball Bearings: Correspond to the design of two single row angular contact ball bearings side by side but occupying less space. They can accommodate radial loads as well as axial loads acting in both directions. They provide a rigid bearing arrangement and accommodate tilting moments well.
Benefits: Compact, rigid, accommodates tilting, radial and axial loads

Brand / Quality:: KSM - Good Quality
Inside Diameter:: 15mm
Outside Diameter:: 35mm
Width:: 15.9mm
Seals / Shields:: Metal Shielded

Technical

---	Bearing Dimensions
d	15mm
D	35mm
B	15.9mm
---	Abutment Dimensions
a	21mm
r1r2 min	0.6mm
r1r2 max	0.6mm
Da min	20mm
da max	30mm
---	Speeds, Weights and Loads
Basic Load Raiting Dynamic Cr	10000 N
Basic Static Load Raiting Cor	6050 N
Limiting Speed in Grease	12000 rpm
Limiting Speed in Oil	17000 rpm
Weight	0.064 kg
