53306 Major Brand Single Thrust Ball Bearing with Spherical Housing Seat U306 30x60x25mm

Name: 53306 Major Brand Single Thrust Ball Bearing with Spherical Housing Seat U306 30x60x25mm
Brand: Major Brand
SKU: 53306?MB
Price: 67.88 EUR
Availability: InStock

€67,88 ex VAT

Sale Sold out

In stock

Price Break

10+ €51,59

19+ €48,69

29+ €48,11

39+ €47,53

49+ €46,95

74+ €46,37

99+ €43,47

199+ €42,89

249+ €42,31

499+ €41,73

999+ €40,57

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly

Brand / Quality:: Major Brand - High Quality
Inside Diameter:: 30mm
Outside Diameter:: 60mm
Width:: 25mm

Technical

d	30mm
D	60mm
H1	25mm
Dynamic load C	37.7 kN
Static load Co	71 kN
Fatigue load limit Pu	2.65 kN
Minimum load factor A	0.026
Reference speed	3800 rpm
Limiting Speed	5300 rpm
Weight	0.33 kg
Seating Washer	U306
d1	60mm
D1	32mm
D2	45mm
D3	62mm
H	22.6mm
C	7mm
R	50mm
s	22mm
r1r2 min	1mm
da max	48mm
Da max	45mm
ra max	1mm
