SKU: 53415M+U415-SKF

SKF 53415M Single Thrust Ball Bearing with Spherical Housing Seat U415 75x160x75mm

Name: SKF 53415M Single Thrust Ball Bearing with Spherical Housing Seat U415 75x160x75mm
Brand: SKF
SKU: 53415M+U415-SKF
Availability: OutOfStock

Out of stock

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly

Brand / Quality:: SKF - High Quality
Inside Diameter:: 75mm
Outside Diameter:: 160mm
Width:: 75mm

Technical

d	75mm
D	160mm
H1	75mm
Dynamic load C	251 kN
Static load Co	610 kN
Fatigue load limit Pu	20.8 kN
Minimum load factor A	1.9
Reference speed	1300 rpm
Limiting speed	1800 rpm
Weight	8.1 kg
Seating washer	U415
d1	160mm
D1	78mm
D2	115mm
D3	165mm
H	69mm
C	21mm
R	125mm
s	42mm
r1r2 min	2mm
da max	126mm
Da max	115mm
ra max	2mm
