SKU: 6012-HT-270-CL-FAG
FAG 6012HT270 High Temp 270C Normal Speed Open Deep Groove Ball Bearing 60x95x18mm Max 80rpm
FAG 6012HT270 High Temp 270C Normal Speed Open Deep Groove Ball Bearing 60x95x18mm Max 80rpm
Equivalent to: 6012VA201 6012VA208 6012VA228
Out of stock
Share this product
Description
Description
HT270 Series High-Temperature Range Deep Groove Ball Bearings: With an operating range from minus 25 degrees up to plus 270 degrees Celsius these bearings are ideally situated in arduous conditions where rapid temperature changes are expected, refrigeration and baking equipment being a good example. Of standard ball bearing construction with an increased radial clearance to compensate for thermal expansion, they are manufactured without seals or shields. The bearings have a BLACK MANGANESE PHOSHPATE coating to the bearings outer surfaces
Benefits: Wide operating temperature range, can be re-lubricated
- Brand / Quality:
- FAG - High Quality
- Inside Diameter:
- 60mm
- Outside Diameter:
- 95mm
- Width:
- 18mm
- Temperature Range:
- High Temp
Technical
Technical
| Inside diameter d | 60mm |
|---|---|
| Outside diameter D | 95mm |
| Width W | 18mm |
| Static load max | 15.8 kN |
| Max operating temperature | 270 deg Celcius |
| Maximum speed | 80 rpm |
| Weight | 420 g |
