SKU: 61801-2Z/C3-SKF
SKF 618012ZC3 Metal Shielded Thin Section Deep Groove Ball Bearing 12x21x5mm
Equivalent to: 61801ZZEC3 61801ZZC3 61801.2ZC3 61801KDDC3 61801DDC3 618012ZRC3 61801FFC3 6801ZZEC3 6801ZZC3 68012ZC3 6801.2ZC3 6801KDDC3 6801DDC3 68012ZRC3 6801FFC3
Out of stock
Share this product
Description
|
Metal Shielded Thin Section Ball Bearings: One of the most commonly used bearings, these types are manufactured with metal shields inserted into the outer raceway, these fit in closely to the inner race providing protection against light mechanical damage, some protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing. |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 12mm
- Outside Diameter:
- 21mm
- Width:
- 5mm
- Seals / Shields:
- Metal Shielded
- Clearance:
- C3
Technical
| d | 12mm |
|---|---|
| D | 21mm |
| B | 5mm |
| Dynamic load C | 1.43 kN |
| Static load Co | 0.67 kN |
| Fatigue load limit Pu | 0.028 kN |
| Reference speed | 70000 rpm |
| Limiting speed | 36000 rpm |
| Weight | 0.0063 kg |
| d1 | 0mm |
| d2 | 14.1mm |
| D2 | 19.1mm |
| r1r2 min | 0.3mm |
| da min | 14mm |
| da max | 14mm |
| Da max | 19mm |
| ra max | 0.3mm |
| Calculation factor kr | 0.015 |
| Calculation factor f0 | 9.7 |
