SKU: 61801-ZZ-CDX
Codex 61801ZZ Metal Shielded Thin Section Deep Groove Ball Bearing 12x21x5mm
Equivalent to: 61801ZZ 618012Z 618012ZR 61801ZZE 61801FF 61801DD 61801DDC 61801KDDC EL12ZZ EL122Z
In stock
Price Break
Couldn't load pickup availability
Share this product
Description
|
Metal Shielded Deep Groove Ball Bearings: One of the most commonly used bearings, these types are manufactured with metal shields inserted into the outer raceway, these fit in closely to the inner race providing protection against light mechanical damage, some protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing. |
- Brand / Quality:
- Codex - Good Quality
- Inside Diameter:
- 12mm
- Outside Diameter:
- 21mm
- Width:
- 5mm
- Seals / Shields:
- Metal Shielded
- Clearance:
- * Standard
Technical
| d | 12mm |
|---|---|
| D | 21mm |
| B | 5mm |
| Dynamic Load | 1.43 kN |
| Static Load | 0.67 kN |
| Fatigue Load Limit Pu | 0.028 |
| Reference Speed | 70000 rpm |
| Limiting Speed | 36000 rpm |
| Weight | 0.0063kg |
| d2 | 14.1mm |
| D2 | 19.1mm |
| r1r2 min | 0.3mm |
| da min | 14mm |
| da max | 14mm |
| Da max | 19mm |
| ra max | 0.3 |
| Calc factor kr | 0.015 |
| Calc factor Cor f0 | 9.7 |
