SKU: 7000CTRDULP3-RHP

RHP 7000CTRDULP3 Super Precision Angular Contact Spindle Bearing 10x26x8mm (Set of 2)

RHP 7000CTRDULP3 Super Precision Angular Contact Spindle Bearing 10x26x8mm (Set of 2)
Regular price €205,51 ex VAT
Regular price Sale price €205,51 ex VAT
Sale Sold out

In stock

Price Break
3+ €156,18
5+ €147,41
10+ €145,65
25+ €143,90
49+ €142,14
74+ €140,39
99+ €131,61
199+ €129,86
249+ €128,10
499+ €126,35
999+ €122,84
Quantity

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
--- Bearing dimensions
d 10mm
D 26mm
B 8mm
r<sub>min</sub> 0.3mm
r1<sub>min</sub> 0.15mm
--- Loads angles and speeds
C<sub>r</sub> 5.6Kn
C<sub>or</sub> 2.49kN
Axial load Kn 2.16 kN
Contact angle 15 degrees
Factor f<sub>o</sub> 12.6
Effective diameter 6.4mm
Max speed in grease 63900 rpm
Max speed in oil 97300 rpm
--- Fitting dimensions
d<sub>a min</sub> 12.5mm
D<sub>a max</sub> 23.5mm
D<sub>b max</sub> 24.8mm
r<sub>a max</sub> 0.3mm
r<sub>b max</sub> 0.15mm
Weight 0.038kg
