• NSK 7008A5TRDULP3 Super Precision Angular Contact Spindle Bearing 40x68x15mm (Set of 2)
1 1

SKU: 7008A5TRDULP3-NSK

NSK 7008A5TRDULP3 Super Precision Angular Contact Spindle Bearing 40x68x15mm (Set of 2)

NSK 7008A5TRDULP3 Super Precision Angular Contact Spindle Bearing 40x68x15mm (Set of 2)
€343,74 ex VAT
€343,74 ex VAT
Sale Sold out

In stock

Price Break
3+ €261,22
5+ €246,55
10+ €243,61
25+ €240,68
49+ €237,74
74+ €234,81
99+ €220,13
199+ €217,20
249+ €214,26
499+ €211,33
999+ €205,46

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
5ZG1TM6ZIA
Brand / Quality:
NSK - High Quality
Inside Diameter:
40mm
Outside Diameter:
68mm
Width:
15mm
Seals / Shields:
None
Style:
Universal Matched Pair of Bearings
Contact Angle:
25 Degree contact angle
Bearing Preload:
Light preload
Technical
--- Bearing dimensions
d 40mm
D 68mm
B 15mm
r<sub>min</sub> 1mm
r1<sub>min</sub> 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 20.5Kn
C<sub>or</sub> 15.1kN
Axial load Kn 12 kN
Contact angle 25 degrees
Factor f<sub>o</sub> -
Effective diameter 20.1mm
Max speed in grease 18600 rpm
Max speed in oil 27800 rpm
--- Fitting dimensions
d<sub>a min</sub> 46mm
D<sub>a max</sub> 62mm
D<sub>b max</sub> 63mm
r<sub>a max</sub> 1mm
r<sub>b max</sub> 0.5mm
Weight 0.376kg
