• NSK 7919A5TRDUDMP3 Super Precision Angular Contact Spindle Bearing 95x130x18mm (Set of 3)
1 1

SKU: 7919A5TRDUDMP3-NSK

NSK 7919A5TRDUDMP3 Super Precision Angular Contact Spindle Bearing 95x130x18mm (Set of 3)

NSK 7919A5TRDUDMP3 Super Precision Angular Contact Spindle Bearing 95x130x18mm (Set of 3)
€1.439,91 ex VAT
€1.439,91 ex VAT
Sale Sold out

In stock

Price Break
3+ €1.072,81
5+ €1.012,54
10+ €1.000,48
25+ €988,43
49+ €976,37
74+ €964,32
99+ €904,05
199+ €892,00
249+ €879,94
499+ €867,89
999+ €843,78

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
BDM8P7Y56R
Brand / Quality:
NSK - High Quality
Inside Diameter:
95mm
Outside Diameter:
130mm
Width:
18mm
Seals / Shields:
None
Style:
Universal Matched Triple Bearing Set
Contact Angle:
25 Degree contact angle
Bearing Preload:
Medium preload
Technical
--- Bearing dimensions
d 95mm
D 130mm
B 18mm
r<sub>min</sub> 1.1mm
r1<sub>min</sub> 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 42Kn
C<sub>or</sub> 45.5kN
Axial load Kn 35 kN
Contact angle 25 degrees
Factor f<sub>o</sub> -
Effective diameter 35.2mm
Max speed in grease 8900 rpm
Max speed in oil 13400 rpm
--- Fitting dimensions
d<sub>a min</sub> 102mm
D<sub>a max</sub> 123mm
D<sub>b max</sub> 125mm
r<sub>a max</sub> 1mm
r<sub>b max</sub> 0.6mm
Weight 1.809kg
