xiros xirodur BB624A50070GL Open Type Polymer Ball Bearing with PEEK Cage and Glass Balls 4x13x5mm
xiros xirodur BB624A50070GL Open Type Polymer Ball Bearing with PEEK Cage and Glass Balls 4x13x5mm
Regular price
€32,62
ex VAT
Regular price
Sale price
€32,62
ex VAT
In stock
Price Break
5+
€24,78
9+
€23,39
29+
€23,11
49+
€22,83
99+
€22,56
199+
€22,28
299+
€20,88
399+
€20,61
499+
€20,33
749+
€20,05
999+
€19,49
Quantity
Couldn't load pickup availability
Description
Description
|
IGUS xiros® xirodur® A500 Polymer Ball Bearings: These open type radial deep groove ball bearings consist of PEEK cages and glass balls. These bearings are suitable for high temperatures up to +150 deg C. These bearings are often used in environments where high chemical resistance is required and stainless steel components should be avoided entirely. Benefits: Lubrication- and maintenance-free, corrosion-resistant, non-magnetic, washable, chemical resistant, lightweight, high-temperature range, life time predictable. |
- Brand / Quality:
- Igus - High Quality
- Inside Diameter:
- 4mm
- Outside Diameter:
- 13mm
- Width:
- 5mm
- Seals / Shields:
- None
- Clearance:
- * Standard
- Temperature Range:
- High Temp
Technical
Technical
| d1 | 4mm |
|---|---|
| d2 | 13mm |
| b1 | 5mm |
| Max static axial load | 56 N |
| Static load capacity | 40 N |
| Dynamic load capacity | 52 N |
| Max speed | 4550 rpm |
| Race | A500 |
| Cage | PEEK |
| Ball material | Glass |
