SKU: C2212KTN9-SKF

SKF C2212KTN9 Carb Toroidal Roller Bearing with Taper Bore 60x110x28mm Allow 7-10 Days

Name: SKF C2212KTN9 Carb Toroidal Roller Bearing with Taper Bore 60x110x28mm Allow 7-10 Days
Brand: SKF
SKU: C2212KTN9-SKF
Price: 210.21 EUR
Availability: InStock

€210,21 ex VAT

Sale Sold out

In stock

Price Break

10+ €159,75

19+ €150,77

29+ €148,98

39+ €147,18

49+ €145,39

74+ €143,59

99+ €134,62

199+ €132,83

249+ €131,03

499+ €129,24

999+ €125,65

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Carb Toroidal Roller Bearings: These compact design bearings have a single row of barrel shaped (spherical) rollers which run on a common spherical outer and inner raceway. Their design offers many features such as self alignment, insensitivity to misalignment, tolerance to heavy radial and axial loads etc. They are manufactured with in both parallel and tapered bore variants and the ability to deliberately displace the position of the rings to each other permits accurate setting of the radial internal clearance.
Benefits: High radial and axial loads, misalignment, taper and parallel bore options

Brand / Quality:: SKF - High Quality
Inside Diameter:: 60mm
Outside Diameter:: 110mm
Width:: 28mm
Seals / Shields:: None

Technical

---	Dimensions
d	60mm
D	110mm
B	28mm
d2	77.1mm
D1	97.9mm
r1r2 min	1.5mm
s1	8.5mm
da min	69mm
da max	77mm
Da min	95mm
Da max	101mm
Ca	0.3mm
ra max	1.5mm
---	Speeds and Loads
Dynamic load C	143 kN
Static load Co	156 kN
Fatigue load limit Pu	18.3 kN
Reference speed	5600 rpm
Limiting speed	7500 rpm
---	Factors
Misalignment factor k1	0.1
Operating clearance factor k2	0.123
---	Weights
Weight	1.1 kg
---	Matching Adaptor Sleeves
Sleeve No.	<a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=H312E+sleeve>H312E</a>
---	Matching Withdrawal Sleeves
Sleeve No.	<a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=AHX312+sleeve>AHX312</a>
