• SKF C2212KV Carb Toroidal Roller Bearing with Taper Bore 60x110x28mm Allow 7-10 Days
1 1

SKU: C2212KV-SKF

SKF C2212KV Carb Toroidal Roller Bearing with Taper Bore 60x110x28mm Allow 7-10 Days

SKF C2212KV Carb Toroidal Roller Bearing with Taper Bore 60x110x28mm Allow 7-10 Days
€231,24 ex VAT
€231,24 ex VAT
Sale Sold out

In stock

Price Break
10+ €175,73
19+ €165,85
29+ €163,88
39+ €161,91
49+ €159,93
74+ €157,96
99+ €148,08
199+ €146,11
249+ €144,14
499+ €142,16
999+ €138,21

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Carb Toroidal Roller Bearings: These compact design bearings have a single row of barrel shaped (spherical) rollers which run on a common spherical outer and inner raceway. Their design offers many features such as self alignment, insensitivity to misalignment, tolerance to heavy radial and axial loads etc. They are manufactured with in both parallel and tapered bore variants and the ability to deliberately displace the position of the rings to each other permits accurate setting of the radial internal clearance.
Benefits: High radial and axial loads, misalignment, taper and parallel bore options
Brand / Quality:
SKF - High Quality
Inside Diameter:
60mm
Outside Diameter:
110mm
Width:
28mm
Seals / Shields:
None
Technical
--- Dimensions
d 60mm
D 110mm
B 28mm
d2 77.1mm
D1 97.9mm
r1r2 min 1.5mm
s1 8.5mm
s2 5.3mm
da min 69mm
da max 91mm
Da max 101mm
ra max 1.5mm
--- Speeds and Loads
Dynamic load C 166 kN
Static load Co 190 kN
Fatigue load limit Pu 22.4 kN
Limiting speed 2800 rpm
--- Factors
Misalignment factor k1 0.1
Operating clearance factor k2 0.123
--- Weights
Weight 1.15 kg
--- Matching Adaptor Sleeves
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=H312+sleeve>H312</a>
--- Matching Withdrawal Sleeves
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=AHX312+sleeve>AHX312</a>
