• igubal EALM17F Left Hand Male Plastic Rod End 17mm Bore M16x1.5 Thread - Allow 2-3 Days
1 1

SKU: EALM-17.F

igubal EALM17F Left Hand Male Plastic Rod End 17mm Bore M16x1.5 Thread - Allow 2-3 Days

igubal EALM17F Left Hand Male Plastic Rod End 17mm Bore M16x1.5 Thread - Allow 2-3 Days
€22,74 ex VAT
€22,74 ex VAT
Sale Sold out

In stock

Price Break
4+ €17,28
9+ €16,31
19+ €16,12
29+ €15,92
39+ €15,73
49+ €15,53
59+ €14,56
69+ €14,37
79+ €14,17
89+ €13,98
99+ €13,59

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
EALM_DESC
Brand / Quality:
Igus - High Quality
Thread Size:
M16x1.5
Thread M / F:
Male
Thread Direction:
Left Hand
Inside Diameter:
17mm
Technical
d1 17mm
d2 46mm
d3 M16x1.5
C1 11mm
B 14mm
h 69mm
l1 37mm
l2 92mm
Max pivot angle 18°
Max static tensile strength (short term) 3600 N
Max static tensile strength (long term) 1800 N
Max radial load (short term) 900 N
Max radial load (long term) 450 N
Min thread depth 26mm
Max torque outside thread 21 Nm
Max torque through ball 35 Nm
Weight 30.2 g
