SKU: GR/SS10DP/16B-0.75_INCH

SS10DP/16B-0.75 Imperial EN8 Steel Spur Gear 16 Tooth 10 DP Bored 0.75 inch (H8)

Name: SS10DP/16B-0.75 Imperial EN8 Steel Spur Gear 16 Tooth 10 DP Bored 0.75 inch (H8)
Brand: Drive-Flex
SKU: GR/SS10DP/16B-0.75_INCH
Price: 83.25 EUR
Availability: InStock

€83,25 ex VAT

Sale Sold out

In stock

Price Break

5+ €63,38

9+ €59,82

19+ €59,11

29+ €58,40

49+ €57,69

74+ €56,97

99+ €53,41

199+ €52,70

249+ €51,99

499+ €51,28

999+ €49,85

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: Drive-Flex - High Quality
Bore:: 19.05mm = 0.75 (3/4) inch
Number of Teeth:: 16
Variant:: Tooth Profile B
Pitch Circle Diameter:: 40.64mm = 1.6 inch
Gear Modulus:: 10DP

Technical

Number of Teeth	16
Pitch (dp)	1.6 inch
Bore (H8)	0.75 inch
Hub / Boss (dm)	1.25 inch
Outside (de)	1.8 inch
Width (A)	1.625 inch
Face Width (B)	1 inch
Modulus / Diametral Pitch DP	10 dp
Tolerance unless otherwise stated	+- 0.01 inch
Pressure Angle	20 degrees
