SKU: HFL.3030.EU
HFL3030 Budget Needle Roller Clutch Type One Way Bearing 30x37x30mm
In stock
Price Break
Couldn't load pickup availability
Share this product
Description
|
Budget Metric Needle Roller Clutch Bearings: Designed to transmit torques in one direction and freewheel in the opposite direction. One-way clutches consist of a thin-walled, drawn outer ring with a series of ramps on the inside diameter, plastic cages, springs and needle rollers. They are supplied pre-greased with lithium soap grease. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 30mm
- Outside Diameter:
- 37mm
- Width:
- 30mm
Technical
| Fw | 30mm |
|---|---|
| D | 37mm |
| C | 30mm (Tolerance: 0/-0.3) |
| r min | 0.3mm |
| Permissable torque | 90 Nm |
| Speed (rotating shaft) | 4500 rpm |
| Speed (rotating outer ring) | 4500 rpm |
| Maximum permissable radial load | 11600 N |
| Limiting load | 16900 N/min |
| Weight | 51 g |
