• igubal KALM12F Left Hand Male Plastic Rod End 12mm Bore M12x1.25 Thread
1 1

SKU: KALM-12.F

igubal KALM12F Left Hand Male Plastic Rod End 12mm Bore M12x1.25 Thread

igubal KALM12F Left Hand Male Plastic Rod End 12mm Bore M12x1.25 Thread
€16,68 ex VAT
€16,68 ex VAT
Sale Sold out

In stock

Price Break
4+ €12,67
9+ €11,96
19+ €11,82
29+ €11,68
39+ €11,53
49+ €11,39
59+ €10,68
69+ €10,54
79+ €10,39
89+ €10,25
99+ €9,97

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
KALM_DESC
Brand / Quality:
Igus - High Quality
Thread Size:
M12x1.25
Thread M / F:
Male
Thread Direction:
Left Hand
Inside Diameter:
12mm
Technical
d1 12mm
d2 34mm
d3 M12x1.25
C1 12mm
B 16mm
h 54mm
l1 32mm
l2 71mm
Max pivot angle 25°
Max static tensile strength (short term) 2700 N
Max static tensile strength (long term) 1350 N
Max radial load (short term) 400 N
Max radial load (long term) 200 N
Min thread depth 22mm
Max torque strength outside thread 6 Nm
Max torque through ball (standard) 30 Nm
Max torque through ball (MH) 70 Nm
Weight 18 g
