igubal KALM16F Left Hand Male Plastic Rod End 16mm Bore M16x1.5 Thread
igubal KALM16F Left Hand Male Plastic Rod End 16mm Bore M16x1.5 Thread
Regular price
€16,33
ex VAT
Regular price
Sale price
€16,33
ex VAT
In stock
Price Break
4+
€12,40
9+
€11,71
19+
€11,57
29+
€11,43
39+
€11,29
49+
€11,15
59+
€10,45
69+
€10,31
79+
€10,17
89+
€10,03
99+
€9,75
Quantity
Couldn't load pickup availability
Share this product
Description
Description
KALM_DESC
- Brand / Quality:
- Igus - High Quality
- Thread Size:
- M16x1.5
- Thread M / F:
- Male
- Thread Direction:
- Left Hand
- Inside Diameter:
- 16mm
Technical
Technical
| d1 | 16mm |
|---|---|
| d2 | 42mm |
| d3 | M16x1.5 |
| C1 | 15mm |
| B | 21mm |
| h | 66mm |
| l1 | 37mm |
| l2 | 88mm |
| Max pivot angle | 23° |
| Max static tensile strength (short term) | 3900 N |
| Max static tensile strength (long term) | 1950 N |
| Max radial load (short term) | 800 N |
| Max radial load (long term) | 400 N |
| Min thread depth | 26mm |
| Max torque strength outside thread | 17 Nm |
| Max torque through ball (standard) | 40 Nm |
| Max torque through ball (MH) | 110 Nm |
| Weight | 34 g |
