• igubal KARM08MH Right Hand Male Plastic Rod End 8mm Bore M8 Thread with Metal Insert
1 1

SKU: KARM-08.MH

igubal KARM08MH Right Hand Male Plastic Rod End 8mm Bore M8 Thread with Metal Insert

igubal KARM08MH Right Hand Male Plastic Rod End 8mm Bore M8 Thread with Metal Insert
€11,68 ex VAT
€11,68 ex VAT
Sale Sold out

In stock

Price Break
4+ €8,87
9+ €8,37
19+ €8,27
29+ €8,17
39+ €8,07
49+ €7,97
59+ €7,48
69+ €7,38
79+ €7,28
89+ €7,18
99+ €6,98

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
KARM_MH_DESC
Brand / Quality:
Igus - High Quality
Thread Size:
M8
Thread M / F:
Male
Thread Direction:
Right Hand
Inside Diameter:
8mm
Technical
d1 8mm
d2 24mm
d3 M8
C1 9mm
B 12mm
h 42mm
l1 25mm
l2 55mm
Max pivot angle 25°
Max static tensile strength (short term) 1700 N
Max static tensile strength (long term) 850 N
Max radial load (short term) 200 N
Max radial load (long term) 100 N
Min thread depth 18mm
Max torque strength outside thread 2 Nm
Max torque through ball (standard) 12 Nm
Max torque through ball (MH) 40 Nm
Weight 7.1 g
