• igubal KBLI03 Left Hand Female Plastic Rod End 0.187 inch Bore 10-32 Thread
1 1

SKU: KBLI-03

igubal KBLI03 Left Hand Female Plastic Rod End 0.187 inch Bore 10-32 Thread

igubal KBLI03 Left Hand Female Plastic Rod End 0.187 inch Bore 10-32 Thread
€17,15 ex VAT
€17,15 ex VAT
Sale Sold out

In stock

Price Break
4+ €13,03
9+ €12,30
19+ €12,15
29+ €12,01
39+ €11,86
49+ €11,71
59+ €10,98
69+ €10,84
79+ €10,69
89+ €10,54
99+ €10,25

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
KBLI_DESC
Brand / Quality:
Igus - High Quality
Thread Size:
10-32
Thread M / F:
Female
Thread Direction:
Left Hand
Inside Diameter:
4.76mm = 0.187 (3/16) inch
Technical
d1 0.187 inch
d2 0.625 inch
d3 10-32 inch
d4 0.406 inch
C1 0.246 inch
B 0.312 inch
h1 1.062 inch
l3 0.5 inch
l4 1.374 inch
W 0.312 inch
Max pivot angle 25°
Max static tensile strength (short term) 900 N
Max static tensile strength (long term) 450 N
Max radial load (short term) 300 N
Max radial load (long term) 150 N
Min thread depth 0.35 inch
Max torque outside thread 2 Nm
Max torque through ball 3 Nm
Weight 3.3 g
