• igubal KBLI04 Left Hand Female Plastic Rod End 0.25 inch Bore 1/4-28 Thread
1 1

SKU: KBLI-04

igubal KBLI04 Left Hand Female Plastic Rod End 0.25 inch Bore 1/4-28 Thread

igubal KBLI04 Left Hand Female Plastic Rod End 0.25 inch Bore 1/4-28 Thread
€10,05 ex VAT
€10,05 ex VAT
Sale Sold out

In stock

Price Break
4+ €7,64
9+ €7,21
19+ €7,12
29+ €7,03
39+ €6,95
49+ €6,86
59+ €6,43
69+ €6,35
79+ €6,26
89+ €6,18
99+ €6,01

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
KBLI_DESC
Brand / Quality:
Igus - High Quality
Thread Size:
1/4-28
Thread M / F:
Female
Thread Direction:
Left Hand
Inside Diameter:
6.35mm = 0.25 (1/4) inch
Technical
d1 0.25 inch
d2 0.75 inch
d3 1/4-28 inch
d4 0.469 inch
C1 0.272 inch
B 0.365 inch
h1 1.312 inch
l3 0.687 inch
l4 1.687 inch
W 0.375 inch
Max pivot angle 25°
Max static tensile strength (short term) 1100 N
Max static tensile strength (long term) 550 N
Max radial load (short term) 400 N
Max radial load (long term) 200 N
Min thread depth 0.48 inch
Max torque outside thread 5 Nm
Max torque through ball 4 Nm
Weight 5.1 g
