• igubal KBRM16MH Right Hand Female Plastic Rod End 16mm Bore M16 Thread with Metal Insert
1 1

SKU: KBRM-16.MH

igubal KBRM16MH Right Hand Female Plastic Rod End 16mm Bore M16 Thread with Metal Insert

igubal KBRM16MH Right Hand Female Plastic Rod End 16mm Bore M16 Thread with Metal Insert
€27,10 ex VAT
€27,10 ex VAT
Sale Sold out

In stock

Price Break
4+ €20,60
9+ €19,44
19+ €19,21
29+ €18,98
39+ €18,75
49+ €18,52
59+ €17,36
69+ €17,13
79+ €16,90
89+ €16,66
99+ €16,20

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
KBRM_MH_DESC
Brand / Quality:
Igus - High Quality
Thread Size:
M16
Thread M / F:
Female
Thread Direction:
Right Hand
Inside Diameter:
16mm
Technical
d1 16mm
d2 42mm
d3 M16
d4 22mm
d5 27mm
C1 15mm
B 21mm
h1 64mm
l3 28mm
l4 85mm
W SW22
Max pivot angle 23°
Max static tensile strength (short term) 4200 N
Max static tensile strength (long term) 2100 N
Max radial load (short term) 1300 N
Max radial load (long term) 650 N
Min thread depth 19mm
Max torque strength inside thread 30 Nm
Max torque through ball (standard) 40 Nm
Max torque through ball (MH) 110 Nm
Weight 39.6 g
