SKU: KBRM-20.F
igubal KBRM20F Right Hand Female Plastic Rod End 20mm Bore M20x1.5 Thread
igubal KBRM20F Right Hand Female Plastic Rod End 20mm Bore M20x1.5 Thread
Regular price
€14,93
ex VAT
Regular price
Sale price
€14,93
ex VAT
In stock
Price Break
4+
€11,35
9+
€10,71
19+
€10,58
29+
€10,45
39+
€10,33
49+
€10,20
59+
€9,56
69+
€9,43
79+
€9,31
89+
€9,18
99+
€8,92
Quantity
Couldn't load pickup availability
Share this product
Description
Description
KBRM_DESC
- Brand / Quality:
- Igus - High Quality
- Thread Size:
- M20x1.5
- Thread M / F:
- Female
- Thread Direction:
- Right Hand
- Inside Diameter:
- 20mm
Technical
Technical
| d1 | 20mm |
|---|---|
| d2 | 50mm |
| d3 | M20x1.5 |
| d4 | 28mm |
| d5 | 34mm |
| C1 | 18mm |
| B | 25mm |
| h1 | 77mm |
| l1 | 33mm |
| l2 | 102mm |
| W | SW30 |
| Max pivot angle | 23° |
| Max static tensile strength (short term) | 5400 N |
| Max static tensile strength (long term) | 2700 N |
| Max radial load (short term) | 2100 N |
| Max radial load (long term) | 1050 N |
| Min thread depth | 22mm |
| Max torque strength inside thread | 60 Nm |
| Max torque through ball (standard) | 55 Nm |
| Max torque through ball (MH) | 200 Nm |
| Weight | 73.5 g |
