• igubal KCLM06MH Left Hand Female Plastic Rod End 6mm Bore M6 Thread with Metal Insert
1 1

SKU: KCLM-06.MH

igubal KCLM06MH Left Hand Female Plastic Rod End 6mm Bore M6 Thread with Metal Insert

igubal KCLM06MH Left Hand Female Plastic Rod End 6mm Bore M6 Thread with Metal Insert
€16,18 ex VAT
€16,18 ex VAT
Sale Sold out

In stock

Price Break
4+ €12,30
9+ €11,61
19+ €11,47
29+ €11,34
39+ €11,20
49+ €11,06
59+ €10,37
69+ €10,23
79+ €10,09
89+ €9,95
99+ €9,68

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
KCLM_MH_DESC
Brand / Quality:
Igus - High Quality
Thread Size:
M6
Thread M / F:
Female
Thread Direction:
Left Hand
Inside Diameter:
6mm
Technical
d1 6mm
d2 20mm
d3 M6
W SW10
B 9
mmC 7mm
h1 30mm
l3 13.5mm
l4 40mm
Max pivot angle 40°
Max static tensile strength (short term) 1400 N
Max static tensile strength (long term) 700 N
Max radial load (short term) 300 N
Max radial load (long term) 150 N
Max torque strength inner threading 0.75 Nm
Weight 4.2 g
